Model: Q96D-BC Q190D-BC Q240D-BC
Type: Double channel double indication
Accuracy: 1.5
Ambient temperature rang: -25° C to +55° C
Q96D-BC Q190D-BC Q240D-BC Ammeter DC
Features of Q96D-BC Q190D-BC Q240D-BC Ammeter DC
Accuracy: 1.5
Ambient temperature rang: -25° C to +55° C
Housing protection: IP42/52
Vibration strength: 0.7g
Front panel dimensions: 96x96mm,72x72mm,.48x48mm, 240x240mm, 190x 190mm
Dial: Black scale and marking on white background.Red scale
Deviation: 90° / 240° (270° as requested)
Dial: Black scale and marking on white background.Red scale
mark for setting value and centre zero scale as requested
Installation: Secured by two diagonal brackets
Model tabel of Q96D-BC Q190D-BC Q240D-BC Ammeter DC
Model | Deviation | Dimensions(A*B*C) | Cutout(D*D) | Weight | Remarks |
Q96D-BC | 90° | 96*96*80 | 92+0.5*92+0.5 | 1.2 | |
Q190D-BC | 96*96*80 | 92+0.5*92+0.5 | 1.2 | ||
Q240D-BC | 96*96*80 | 92+0.5*92+0.5 | 1.2 |
