XMD-16A XMD-16H XMD-16F Digital detector

XMD-16A XMD-16H XMD-16F Digital detector

XMD-16A XMD-16H XMD-16F Digital detector is made of special chip with high intelligence. 1-6 channels can be selected at will, manual / automatic patrol can be switched, and each channel can be set at will Lower limit alarm, with 4 alarm contact outputs. It can be used with various sensors and transmitters to realize the measurement, display and public alarm control of 8, 16 or 32 physical quantities such as temperature, humidity, pressure, liquid level and flow.

XMD-16A XMD-16H XMD-16F allows each channel to select different input sensors, and each channel has independent zero and gain correction functions, as well as independent alarm limit setting functions. The accuracy is ± 0.5% FS ± ldig. It is made of special chip and has high intelligence. 1-6 channels can be selected arbitrarily, and manual / automatic patrol inspection can be switched. Each channel can set the upper and lower limit alarms arbitrarily, and there are 4 alarm contact outputs. Small size and reliable installation structure.

Main features of xmd-16a intelligent digital patrol instrument

1. Digital calibration technology, no potentiometer and other adjustable components.

2. Universal signal input, common thermal signals can be connected through menu setting.

3. The special integrated instrument chip has more reliable anti-interference and stability.

4. The anti-interference mode of combining software and hardware can effectively suppress on-site interference signals.

5. Display range, transmission output range, alarm value and alarm mode can be modified through online menu.

6. Automatic compensation of thermocouple cold end temperature and thermal resistance lead resistance.

7. The measurement range and upper and lower limit alarm values of each channel can be set separately.

8. Pass electromagnetic compatibility (EMC) test from input, output and power supply.

9. It has the functions of fast patrol and fixed-point monitoring, and the patrol time can be set.
