XSJ-97A XSJ-97F XSJ-97H Flow totalizer

XSJ-97A XSJ-97F XSJ-97H Flow totalizer

Overview of XSJ-97A XSJ-97F XSJ-97H Flow totalizer

The flow totalizer controller collects, displays, controls, transmits, communicates and prints various signals such as temperature, pressure and flow on site to form a digital acquisition system and control system. It has liquid crystal and digital displays and various dimensions, and is applicable to the flow totalizer measurement and control of various liquids, general gases, superheated steam and saturated steam; It can be used with various flow sensors or transmitters for quantitative/batch control of media (with start, stop and reset functions), and can adapt to various measurement and control occasions.

Input form

Voltage: 0~5V.DC、1~5V.DC

Electric current: 0~10mA. DC,4～20 mA.DC

Frequency: 0.01~10000Hz

Output form

Four way relay contact output can be used for instantaneous flow alarm or cumulative flow control.

Type F has only two relay outputs

The current output of the transmission output instrument corresponds to the measured transmission signal. Transmitter power supply 24V.DC

Power supply: 220V ± 10%, 50Hz ± 5%
